COOLING

• Capacity (MEPS) : 12750 W

• Running Current : 17.2 A
• Input : 3930 W
• A.E.E.R Rated : 3.22
• Star Rating : 1.5
• Outdoor Operating Temperature Range : -15~50 C

HEATING

• Capacity (MEPS) : 13800 W

• Running Current : 19.0 A
• Input : 4300 W
• A.C.O.P Rated : 3.16
• Star Rating : 1.5
• Outdoor Operating Temperature Range : -15~24 C

POWER SUPPLY - 230V

PHASE - FREQUENCY - 1Ph ~ 50Hz

MOISTURE REMOVAL - 4 L/Hr

FAN SPEEDS - 3 + Auto

AIR CIRCULATION - 640 L/s

COMPRESSOR TYPE - Scroll

I.U. SOUND PRESSURE LEVEL (HI) - 54 / 51 / 48 dBA@1m

O.U. SOUND PRESSURE LEVEL - 62 dBA@1m

O.U. SOUND POWER LEVEL - 71 dB(A)

REFRIGERANT TYPE - R410A

CONNECTION PIPE SIZES -
9.52 Liquid
19.0 Gas

MAX. PIPE LENGTH - 40 m

MAX. HEIGHT DIFFERENCE - 20 m

PIPE CONNECTION METHOD - Flare

DIMENSIONS
INDOOR :(HxWxD) - 287 mm x 840 mm x 840 mm

NET WEIGHT - 31 Kg

FASCIA PANEL (WxD) - 950 mm x 950 mm

OUTDOOR (HxWxD) - 1369 mm x 938 mm x 392 mm

NET WEIGHT - 116 Kg
