COOLING
- Capacity (MEPS) : 7100 W
- Running Current : 9.2 A
- Input : 2090 W
- A.E.E.R Rated : 3.34
- Star Rating : 2
- Outdoor Operating Temperature Range : -15~50 C
HEATING
- Capacity (MEPS) : 7650 W
- Running Current : 9.6 A
- Input : 2150 W
- A.C.O.P Rated : 3.49
- Star Rating : 2.0
- Outdoor Operating Temperature Range : -15~24 C
POWER SUPPLY - 230V
PHASE - FREQUENCY - 1Ph ~ 50Hz
MOISTURE REMOVAL - 1.5 L/Hr
FAN SPEEDS - 3 + Auto
AIR CIRCULATION - 440 L/s
COMPRESSOR TYPE - Rotary
I.U. SOUND PRESSURE LEVEL (HI) - 49 / 45 / 41 dBA@1m
O.U. SOUND PRESSURE LEVEL - 58 dBA@1m
O.U. SOUND POWER LEVEL - 69 dB(A)
REFRIGERANT TYPE - R410A
CONNECTION PIPE SIZES -
9.52 Liquid
15.88 Gas
MAX. PIPE LENGTH - 25m
MAX. HEIGHT DIFFERENCE - 12m
PIPE CONNECTION METHOD - Flare
DIMENSIONS
INDOOR :(HxWxD) - 245 mm x 840 mm x 840 mm
NET WEIGHT - 24 Kg
FASCIA PANEL (WxD) - 950 mm x 950 mm
OUTDOOR (HxWxD) - 862 mm x 895 mm x 313 mm
NET WEIGHT - 59 Kg
