| Model No. - Indoor |
AUTG09LVLB |
| Model No. - Outdoor |
AOTG09LBCB |
| Reverse Cycle System |
Yes |
| Capacity Class |
|
| Cooling Capacity (Watts) |
2,600 |
| Cooling Capacity (BTU/h) |
8,870 |
| Range (Watts) |
900 - 3,600 |
| Range (BTU/h) |
3,000 - 11,900 |
| Heating Capacity (Watts) |
3,500 |
| Heating Capacity (BTU/h) |
11,900 |
| Range (Watts) |
900 - 4,480 |
| Range (BTU/h) |
3,000 - 15,200 |
| Power Supply (Volts) |
240 |
| Phase-Frequency (Ph - Hz) |
5050 |
| Power Supply Attachment |
Outdoor Unit |
| Plug Size (If Applicable) |
Hard Wired |
| Running Current, Cooling (Amps) |
2.9 |
| Running Current, Range (Amps) |
Maximum - 9.3 |
| Input, Cooling (Watts) |
600 |
| Input, Range (Watts) |
Maximum - 1,920 |
| Running Current, Heating (Amps) |
4.1 |
| Running Current, Range (Amps) |
Maximum - 10.8 |
| Input, Heating (Watts) |
830 |
| Input, Range (Watts) |
Maximum - 2,280 |
| Input (Watts) |
- |
| Moisture Removal (l/hr) |
0.50 |
| E.E.R. - Cooling |
4.33 |
| C.O.P. - Heating |
4.22 |
| Star Rating - Cooling |
3.5 |
| Star Rating - Heating |
3.5 |
| Fan Speed |
4 |
| Air Circulation, High (l/s) |
150 |
| Compressor Type |
Twin Rotary X 1 |
| Dimensions - Inside Unit (HxWxD mm) |
245 X 570 X 570 |
| Weight - Inside Unit (kg) |
15 |
| Dimensions - Outside Unit (HxWxD mm) |
620 X 790 X 290 |
| Weight - Outside Unit (kg) |
39 |
| I.U. Sound Pressure Level (dBA@1mtr) |
34 |
| O.U. Sound Pressure Level (dBA@1mtr) |
49 |
| O.U. Sound Power Level (dBA) |
59 |
| Refrigerant Type |
R410A |
| Connection Pipe Sizes, Gas (mm) |
ɸ 9.52 |
| Connection Pipe Sizes, Liquid (mm) |
ɸ 6.35 |
| Pre Charged Length (Metre) |
15 |
| Minimum Pipe Length (Metre) |
3 |
| Maximum Pipe Length (Metre) |
20 |
| Maximum Pipe Height (Metre) |
15 |
| Pipe Connection Methods |
Flare |
| Outdoor operating Temp, Cooling ℃ |
-10 to 46 |
| Outdoor operating Temp, Heating ℃ |
-15 to 24 |
