Key Features
- 5.0kW Cooling Capacity
- 6.1kW Heating Capacity
- EER ( Cooling ) 3.2
- COP ( Heating ) 3.5
- All DC Controlled - Including DC Controlled indoor unit
- Power active module (PAM system) Ensures optimum efficiency
- Twin Inverter rotary compressor For smoother quieter operation
- Lower impact on the environment due to higher operating efficiencies and the use of a non-ozone depleting refrigerant, R410A
- Full flat fascia panel - For smoother, quieter airflow
- Auto restart - Memorises last settings prior to power failure and restarts at the same settings
- Lamba Heat Exchanger - For optimum cooling and heating operation
- Clean Air – Prefilter with 2 stage Nano titanium filtration*, Anti bacterial tangential fan, for cleaner air. *Nano Titanium Filtration is standard on RAS 50, 60, 70 and 80 models and optional on the RAS 25 and 35 models.
- Multi directional airflow - For smoother air distribution
- Low Start current - Minimizing power input
- Anti corrosion coating - Improves coil durability
- LCD Remote Control
- 5 Year full domestic warranty
- Star rating ( Cool / Heat ) 2.0 / 3.0
| MODEL INDOOR UNIT | RAS-50YHA3 |
| MODEL OUTDOOR UNIT | RAC-50YHA3 |
| CAPACITY | |
| COOLING CAPACITY (kW) | 5.00 |
| RANGE (kW) | 0.9 - 5.8 |
| HEATING CAPACITY (kW) | 6.1 |
| RANGE (kW) | 0.9 - 6.8 |
| HEATING CAPACITY H2 (kw) | 5.55 |
| COMPRESSOR TYPE | Rotary |
| EFFICIENCY | |
| INPUT kW (COOLING) | 1.48 |
| INPUT kW (HEATING) | 1.66 |
| MOISTURE REMOVAL (L/hr) | 2.8 |
| AEER COOLING / ACOP HEATING | 3.31 / 3.60 |
| COP H2 | 2.92 |
| RUNNING CURRENT (AMPS) | 7 |
| AIRFLOW | |
| FAN SPEEDS | 4 |
| AIR FLOW (L/s) Hi/Med/Low/ExLow (Sleep) | 227/173/117/(87) |
| DIMENSIONS & WEIGHTS | |
| DIMENSIONS IU (HxWxD mm) | 295/1030/207 |
| WEIGHT IU (Kg) | 11 |
| DIMMENSION OU (HxWxD) | 650/850/298 |
| WEIGHT OU (Kg) | 45 |
| NOISE LEVELS | |
| SOUND PRESSURE LEVEL IU Db(A) Hi/Med/(Sleep) | 47/39/28/(24) |
| SOUND PRESSURE LEVEL OU Db(A) C/H | 50/52 |
| INSTALLATION | |
| REFRIGERANT TYPE | R410 |
| PIPE CONNECTION SIZES: GAS (mm) (in) | 12.7/ (1/2) |
| PIPE CONNECTION SIZES: LIQUID (mm) (in) | 6.35 / (1/4) |
| REFRIGERANT PIPE CHARGE LENGTH (Mtrs) | 20 |
| MAX PIPE LENGTH (Mtrs) | 20 |
| MAX PIPE LIFT (Mtrs) | 10 |
| PIPE CONNECTION METHODS | FLARE |
| WORKING RANGE | |
| Outdoor Operating Temp (Cooling)°C dB | -10 ~ +46 |
| Outdoor Operating Temp (Heating) °CwB | -15 ~ +21 |
| FEATURES | |
| Air Purifying Filter | Yes |
| Nano Titanium Stainless Pre-Filter | Yes |
| Anti Corrosion Fin (O/U Coil) | Green |
| Indoor Fan – Anti-Bacterial Coating | Yes |
| Multi-Directional Air Flow | - |
| All DC Inverter Control Indoor/Outdoor | Yes |
| Wired Remote SPX-RCK3 | Optional |
| Optional Weekly Timer SPX-WKTI | Optional |
| Optional Weekly Timer Distributor SPX-DSTI | Optional |
