Model Name				RJ100F5HXEAXSA
Power Supply			∅, #, V, Hz	1, 2, 220~240, 50
Mode			-	Heat Pump
Performance	HP		HP	3.5
	Capacity Input (Nominal)	Cooling1	kW	10.0
			Btu/h	34,100
		Heating2	kW	12.0
			Btu/h	40,900
Power	Power Input (Nominal)	Cooling1	kW	2.90
		Heating2		2.93
	Current Input (Nominal)	Cooling1	A	13.30
		Heating2		13.40
Energy Efficiency	Nominal Cooling1		-	3.45
	Nominal Heating1		-	4.10
Compressor	Type		-	Inverter Twin Rotary
	Model Name		-	UG8T300FUBJU
	Oil	Type	-	POE
		Initial Charge	cc	1200
Fan	Type		-	Propeller Fan/ BLDC
	Output		W	150
	Number of Units		EA	1
	Air Flow Rate		CMM	70.6
Piping Connections	Liquid Pipe		∅, mm	6.35 x 5
			∅, inch	1/4 x 5
	Gas Pipe		∅, mm	9.52 x 2 + 12.7 x 3
			∅, inch	3/8 x 2 + 1/2 x 3
	Installation Limitation	Total Piping Length	m	80.0
		Max. Length (Outdoor to indoor)	m	25.0
		Max. Height (Between indoors)	m	7.5
		Max. Height (Between ID/OD)	m	15.0
Refrigerant	Type		-	R410A
	Factory Charging		kg	3.3
Sound3	Sound Pressure		dB(A)	52
External Dimension	Net Weight		kg	75
	Shipping Weight		kg	80
	Net Dimensions (WxHxD)		mm	940 x 998 x 330
	Shipping Dimensions (WxHxD)		mm	995 x 1,096 x 426
Operating Temp. Range	Cooling		˚C	-10 ~ 26
	Heating		˚C	-15 ~ 24

1) Nominal cooling capacities are based on; Indoor temperature : 27˚C DB, 19˚C WB / Outdoor temperature : 35˚C DB, Equivalent refrigerant piping : 5m(10kW), 7.5m(7/8kW), Level differences : 0m

2) Nominal heating capacities are based on; Indoor temperature : 20˚C DB, 15˚C WB / Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 5m(10kW), 7.5m(7/8kW), Level differences : 0m

3) Sound level was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
