| Model No. - Indoor |
ASTG07LVCA |
| Reverse Cycle System |
Yes |
| Cooling Capacity (Watts) |
2300 |
| Cooling Capacity (BTU/h) |
7854 |
| Range (Watts) |
2700 |
| Range (BTU/h) |
9220 |
| Heating Capacity (Watts) |
2700 |
| Heating Capacity (BTU/h) |
9220 |
| Range (Watts) |
2700 |
| Range (BTU/h) |
9220 |
| Power Supply (Volts) |
240 |
| Phase-Frequency (Ph - Hz) |
1-50 |
| Power Supply Attachment |
Outdoor |
| Plug Size (If Applicable) |
NA |
| Running Current, (Amps) |
0.14 |
| Input (Watts) |
16 |
| Fan Speed |
4 |
| Compressor Type |
Twin Rotary |
| Dimensions -Inside Unit (HxWxD mm) |
293x790x225 |
| Weight - Inside Unit (Kg) |
9.5 |
| I.U Sound Pressure Level (dBA@1mtr) |
36 |
| O.U. Sound Pressure Level (dBA@1mtr) |
50 |
| O.U. Sound Power Level (dBA) |
64 |
| Refrigerant Type |
R410A |
| Connection Pipe Sizes, Gas (mm) |
9.52 |
| Connection Pipe Sizes, Liquid (mm) |
6.35 |
| Minimum Pipe Length (Metre) |
5 |
| Maximum Pipe Length (Metre) |
24 |
| Maximum Pipe Height (Metre) |
10 |
| Pipe Connection Methods |
Flare |
| Outdoor operating Temp, Cooling ℃ |
0 to 46 |
| Outdoor operating Temp, Heating ℃ |
-10 to 24 |
